XHC

Multistage technology that generates high pressure through smarter hydraulic design rather than a larger pump.

• All-stainless-steel hydraulic construction (304 SS / 316 SS)
• Multistage design for high-pressure applications
• Ultra-quiet operation
• High-efficiency IE2/IE3 motor options
• Reliable construction with a mechanical seal
• Suitable for fluid temperatures up to 110 °C
• Compact and durable design
• Thermal protection in single-phase models
• An ideal solution for industrial and commercial applications
• Long service life and low maintenance requirements

• Maximum Flow Rate (Q): 10 m³/h
• Maximum Head (H): 90 mWC
• Motor Power: 0.25–3 kW
• Voltage: 230 V / 3 × 400 V
• Protection Class: IP54
• Frequency: 50 Hz
• Compliant with EN and IEC standards
• Maximum Operating Pressure: 10 bar
• Connection Sizes: G1"–G1½"
• Fluid Temperature: Up to 110 °C

• All-stainless-steel casing (304 SS / 316 SS)
• Mechanical seal
• IE2/IE3 TEFC motors
• Thermal protection in single-phase models
• Ultra-quiet operation technology

• Cooling systems
• Irrigation systems
• Circulation applications
• Water transfer systems
• Pressure boosting systems
