WTX

The robust stainless steel centrifugal pump that brings different processes together on a common hydraulic platform.

• All-AISI 316 stainless steel hydraulic construction
• Designed for high-flow industrial applications
• Single-stage centrifugal pump technology
• Suitable for process and aggressive fluid applications
• Compact, close-coupled design with no coupling
• Special mechanical seal options
• High-efficiency IE2/IE3 motor options
• Suitable for fluid temperatures up to 110 °C
• DN32–DN80 connection options
• Reliable and long-lasting operation

• Maximum Flow Rate (Q): 200 m³/h
• Maximum Head (H): 75 mWC
• Motor Power: 1.1–37 kW
• Voltage: 3 × 400 V
• Protection Class: IP54
• Frequency: 50 Hz
• Compliant with EU Regulation 547/2012
• Maximum Operating Pressure: 10 bar
• Connection Sizes: DN32–DN80
• Fluid Temperature: Up to 110 °C

• All-AISI 316 stainless steel casing and hydraulic components
• Mechanical seal
• Single-stage centrifugal design
• IE2/IE3 TEFC motors
• Close-coupled, coupling-free construction

• Cooling systems
• Irrigation systems
• Water transfer applications
• Firefighting systems
• Pressure boosting systems
• Industrial process applications
