WTM

The centrifugal pump that reinterprets the long-established standard of industrial fluid transfer through modern manufacturing principles.

• Close-coupled horizontal single-stage centrifugal design
• High flow capacity up to 400 m³/h
• Head up to 151 mWC
• An ideal solution for HVAC and industrial applications
• Cast iron casing and durable hydraulic construction
• Reliable design with a mechanical seal
• High-efficiency IE2/IE3 motor options
• Compact and maintenance-friendly construction
• Wide range of capacities and models
• Long-lasting, uninterrupted operating performance

• Maximum Flow Rate (Q): 400 m³/h
• Maximum Head (H): 151 mWC
• Motor Power: 0.75–160 kW
• Voltage: 3 × 400 V
• Protection Class: IP54
• Frequency: 50 Hz
• Compliant with EU Regulation 547/2012
• Maximum Operating Pressure: 16 bar
• Connection Sizes: DN32–DN125
• Fluid Temperature: Up to 120 °C

• Cast iron casing
• Cast iron impeller
• Mechanical seal
• Single-stage centrifugal design
• IE2/IE3 TEFC motors
• Close-coupled, coupling-free construction

• Cooling systems
• Irrigation systems
• Water transfer applications
• Firefighting systems
• Pressure boosting systems
• HVAC applications
