SCP

The double-suction centrifugal pump that combines high flow capacity with balanced hydraulics and easy maintenance.

• Double-suction impeller design
• Ultra-high flow capacity up to 8,500 m³/h
• High head capacity up to 180 mWC
• Easy maintenance through split-case construction
• Designed for heavy-duty applications
• Double-suction hydraulic design that balances axial loads
• Cast iron, ductile iron, stainless steel, and duplex options
• High-efficiency IE3/IE4 motor options
• An ideal solution for firefighting systems and critical infrastructure
• Long service life and high operating reliability

• Maximum Flow Rate (Q): 8,500 m³/h
• Maximum Head (H): 180 mWC
• Motor Power: 30–2,000 kW
• Voltage: 3 × 400 V
• Protection Class: IP54
• Frequency: 50 Hz
• Compliant with EU Regulation 547/2012
• Maximum Operating Pressure: 16/25 bar
• Connection Sizes: DN65–DN700
• Fluid Temperature: Up to 120 °C

• Cast iron casing
• Ductile iron options
• Stainless steel options
• Duplex stainless steel options
• Mechanical seal
• Single-stage centrifugal design
• Double-suction impeller
• IE3/IE4 TEFC motors
• Long-coupled split-case design

• Cooling systems
• Irrigation systems
• Water transfer applications
• Firefighting systems
• Pressure boosting systems
• Industrial process applications
• HVAC applications
