BC

The centrifugal pump that combines corrosion-resistant construction with open-impeller hydraulics.

• Open-impeller design
• Self-priming operation
• All-bronze casing compliant with EN 1982
• Suction depth up to 8 metres
• Suitable for liquids containing moderate levels of solids
• Suitable for seawater and marine applications
• Stainless steel shaft
• Reliable operation with a mechanical seal
• High-efficiency IE2/IE3 motor options
• An ideal solution for industrial and agricultural applications

• Maximum Flow Rate (Q): 15 m³/h
• Maximum Head (H): 20.5 mWC
• Motor Power: 0.15–1.1 kW
• Voltage: 230 V and 3 × 230/400 V
• Protection Class: IP54
• Frequency: 50/60 Hz
• Compliant with EN and IEC standards
• Maximum Operating Pressure: 6 bar
• Maximum Suction Depth: 8 m
• Connection Sizes: G½" / G1" / G1½"
• Fluid Temperature: −10 °C to +90 °C

• All-bronze casing compliant with EN 1982
• Stainless steel shaft
• Mechanical seal
• IE2/IE3 TEFC motors
• Thermal protection in single-phase models

• Transfer of slightly contaminated liquids
• Emulsion transfer applications
• Industrial applications
• Agricultural applications
• Marine applications
